FOX RACING SHOX

FOX FLOAT X FACTORY 2pos-Adj Evol LV 2027 Rear Shock

The FOX FLOAT X FACTORY rear shock is designed for demanding all-mountain and aggressive trail riders. Its monotube design features a new high-flow main... Read more
679,90 €
679,90 €
View full details

Description

The FOX FLOAT X FACTORY rear shock is designed for demanding all-mountain and aggressive trail riders. Its monotube design features a new high-flow main piston, delivering rear-wheel sensitivity, support and grip close to that of the FLOAT X2.

This model features a Kashima Coat finish for greater surface durability and smooth operation over time. The size-specific piggyback reservoir increases oil volume and adds a secondary compression circuit for improved small-bump sensitivity.

The high-volume EVOL Air Sleeve technology allows lower air pressures for a more linear feel and consistent performance on long descents. The three tool-free adjustments (low-speed compression, low-speed rebound and a two-position Open/Firm lever) make it easy to adapt quickly to the terrain.

With reinforced MCU bumpers and bearing-compatible mounts at both ends, this Factory Series rear shock combines performance, reliability and versatility to tackle the most technical trails.

Ref: 16138721263996

Technical information

Design: Monotube with a next-generation high-flow main piston for sensitivity, support and traction close to the 2026 FLOAT X2
Upper tube finish: Kashima Coat
Standard mount

Spring: EVOL LV (air); air-spring or coil-spring options depending on configuration
Reservoir: Piggyback reservoir sized for each shock body, for an optimal performance-to-weight ratio and consistent performance on long descents
High-flow main piston
Progressive bottom-out bumper
Reinforced, more durable MCU assembly for improved performance and longevity
Low-friction air seals
Low friction;
Highly durable hard-chrome shock piston
Two-position lever (Open/Firm) for efficient power transfer on climbs
High-speed compression and rebound adjustment (HSC and HSR) in 8 clicks
Low-speed compression and rebound adjustment (LSC and LSR) in 16 clicks

Updated compression ratio; 300 psi maximum
Improved high-speed rebound adjustment with the addition of VVC (Variable Valve Control)
Greater control and less harshness thanks to linear damping
Independent firm-mode circuit: 2pos-Adj lockout is firmer than on the previous FLOAT X2;
Finned inner body for greater structural rigidity and reduced hysteresis.
Top-out bumper: Improved design for quieter operation
Mount compatibility: Compatible with bearings at both ends

Weight: from 459 g
;

Price information

*Recommended retail price from supplier in September 2026
