ZEEN SUPERLITE Frame Kit+ZEEN ROAD COMBO Handlebar

Designed for cyclists seeking maximum efficiency, the ZEEN SUPERLITE frame embodies a modern vision of road performance. Its monocoque construction and exceptionally low weight deliver dynamic, precise handling... Read more
1.999,80 €
1.999,80 €
View full details

Highlights

  • Lightweight and high-performance monocoque construction
  • Premium Japanese Torayca® carbon fibres
  • Reliable and stiff T47 bottom bracket shell
  • Durable and compatible UDH universal derailleur hanger

Description

Designed for cyclists seeking maximum efficiency, the ZEEN SUPERLITE frame embodies a modern vision of road performance. Its monocoque construction and exceptionally low weight deliver dynamic, precise handling on every type of road. Every detail of the frame has been developed to optimise efficiency, lightness and ride feel on the most demanding outings.

With its stiff, streamlined structure, the ZEEN SUPERLITE promotes direct power transfer. This carefully controlled stiffness enables efficient surges, sharp acceleration and excellent stability on high-intensity climbs. Its lively, precise handling meets the expectations of riders seeking a bike focused on pure performance.

The frame benefits from Zeen’s technical expertise and a carefully selected range of premium materials. Japanese Torayca® fibres and T1100, T800 and T700 composites provide an excellent balance of low weight and stiffness. The attention to finish reflects a design that makes no compromises.

Equipped with the T47 standard and a UDH derailleur hanger, this frame also prioritises durability, compatibility and easy maintenance. It offers a reliable, worry-free ride on any road.

Ref: 15964816638332

Technical information

► DETAILS ◄

○ Use: Long rides and sportive events
○ Carbon type: Toray 38% T1100 - 52% T800 - 12% T700
○ Tested by the German TÜV laboratory
○ Warranty: 2 years

► WEIGHT ◄

○ Maximum loaded weight: 110 kg
○ Frame weight (size M, without seatpost): 780 g
○ Fork weight: 375 g

░░░░░░░░░░░░░░░░░░

► STANDARDS ◄

∟ Frame

○ Bottom bracket: T47 internal, not supplied
○ Headset: integrated 1-1/2"/1-1/2", supplied with 1"1/8 expander plug and headset spacers compatible with an integrated stem
○ UDH derailleur hanger supplied
○ Braze-on mount for fitting a chain catcher or front derailleur

∟ Axles

○ Front wheel axle: 12x100 mm, supplied
○ Rear wheel axle: 12x142 mm, supplied

∟ Drivetrain

○ Rear derailleur compatibility: electronic or cable-operated
○ Front derailleur compatibility: electronic only
○ Internal cable routing

∟ Tyres

○ Maximum tyre size: 700x34

∟ Components

○ Seatpost clamp: integrated into the frame
○ Seatpost: supplied; compatible with round saddle rails only

∟ Brakes

○ Brakes: flat-mount disc
○ Minimum rotor diameter: 160 mm front and 140 mm rear

░░░░░░░░░░░░░░░░░

► INCLUDED ◄

○ ZEEN aerodynamic carbon seatpost
○ ZEEN SUPERLITE carbon fork
○ Headset bearings
○ Set of headset spacers
○ Expander plug
○ Front and rear axles

Handlebar: Construction: Japanese Torayca® carbon fibre
Full carbon monocoque
Geometry:
Compact shape, 70 mm reach
125 mm drop
3° flare
-5° angle
Steerer diameter:
1"1/8
Stem length:
90 to 130 mm
Handlebar width:
370 mm, 380 mm, 410 mm, 430 mm
Features:
Designed specifically for gravel bikes with internal cable routing
Integrated cable routing for electronic and mechanical drivetrains
Weight: not specified
;

Pricing information

*Supplier recommended retail price in May 2026
